1000kg/hr LDPE LLDPE Film Crushing Washing Squeezing Recycling Production Line
Get high quality and high capacity of 1000kg/hr LDPE LLDPE Film Crushing Washing Squeezing Recycling Production Line at Retech Machine, we are top manufacturer of plastic recycling field. Inquiry now!
At a Glance
Equipment Overview
- Category
- Washing Machine
- Capacity options
- 300kg/h, 500kg/h, 1000kg/h
- Typical application
- LDPE agriculture film,LLDPE stretch film,PP woven bag,PP jumbo bag scrap.
- Output
- Clean flakes or recycled pellets — confirmed per project
Product 01
Overview
Our PP PE film crushing washing squeezing drying production line is used to recycle and reprocessing waste plastic like LDPE agriclture film,LLDPE stretch film,PP woven bag,PP jumbo big bag,etc.
After processing,the final film humidity will be less than 5%,it could send to our compactor pelletizing machine to make granules directly.We could supply the PP PE film washing line between 300kg/h to 2000kg/h.
Product 02
Applications & Suitable Materials
LDPE agriculture film,LLDPE stretch film,PP woven bag,PP jumbo bag scrap.
Product 03
Cleaning Process
- * Shredder machine or Crusher depend on the shape and size of plastic film.
- * Unique design of new angle blades in crusher to max capacity.
- * High speed friction washer and label remover system to separate film and stickers especially for LLDPE packaging film.
- * Film squeezing machine or centrifuge dryer optionally.
- * Rich experience for different PE film recycling solutions.
| No | Equipment name | Quantity |
|---|---|---|
| 1 | Belt conveyor | 1 |
| 2 | Shredder/Wet film crusher | 1 |
| 3 | Double screw conveyor | 1 |
| 4 | Film floating tank | 1 |
| 5 | Screw conveyor | 1 |
| 6 | High speed friction washer | 1 |
| 7 | Screw conveyor | 1 |
| 8 | Squeezing machine | 1 |
| 9 | Storage hopper | 1 |
| 10 | Electric panel | 1 |
Technical Data
Specifications & Parameters
| Model | Power | Water | Capacity |
|---|---|---|---|
| RM300 | 85kw/h | 4-6 t/h | 300kg/h |
| RM500 | 155kw/h | 6-8 t/h | 500kg/h |
| RM1000 | 320kw/h | 8-10 t/h | 1000kg/h |
Quality
Quality Assurance
Final moisture between 3%-5%.Dry and clean.
Use world famous brand parts,like Siemens motor,Fuji Inverter,SKF bearing,SUS 304 stainless steel,SKD-11 blades,etc.
Video
Machine Video
Video plays on demand. Source: Retech Machine official channel.
FAQ
1000kg/hr LDPE LLDPE Film Crushing Washing Squeezing Recycling Production Line — Questions
Are you trading company or manufacturer?
We are a manufacturer which producing the machines by ourselves.
What’s your guarantee or the warranty of the quality if we buy your machines?
Our warranty year is one year. During the period, we provide you spare parts free of charge asap. But the technical guide is forever.
How can I install my machine when it arrives?
We will send the instruction manual and videos to you,your workers can install the machine accorded to it. If the situation is ok, we can arrange our engineer to your factory, who will teach your labors how to install machines.
How to maintenance machines in factory?
We will provide maintenance instruction, it will mark the oil model and time. And how many times you should check the machines. Any problems about machines, you can ask us anytime.
If our machine is not working suddenly, but we have not spare parts, how to solve?
We promise our machine’s quality. Also we will prepare enough spare parts from the beginning for using urgently. Some vulnerable parts(blades), we will suggest you to buy. The last way,we send you spare parts by DHL.
How to maintence recycling machine:
We will send you manuals for product maintenance and how to solve common problems. By the way, you can contact with us, we will try our best to teach you by instruction book or video.
Warranty:
We provide 12 months’ warranty period usually.In this Period, any machine’s quality problem,we will send spare parts soon by DHL. We will do our best to teach your worker how to change the spare parts by video or instruction.
24hours technical service:
We will online 24 hours every day, You can contact with us anytime. Our engineer will send you machine maintenance manuals.
