Our PP PE film crushing washing drying recycling line is used to recycle plastic like LDPE LLDPE film,PP woven bag,PP jumbo bag.etc. By our PP PE film recycling machine,the final humidity of film flakes will be less than 5%, it could send to our pelletizing machine to make granules directly. We can supply customized plastic recycling solutions according to client's specific requirements between capacity 300kg/hr-2000kg/hr.

Share this:

Product Description

Our PP woven bag crushing/washing/squeezing/drying production line is mainly designed to deal with waste plastics like PP woven bag, PP jumbo big bag, materials of LDPE agriculture film, LLDPE stretch film also supports. offers pp woven bag recycling solutions that are high output and low energy consumption. As a top manufacturer of plastic recycling field, Retech Machine offers pp woven bag recycling solutions with high output and low energy consumption.

The whole process includes shredding, water rinsing, friction washing, dring and washing system, the final film humidity will be less than 5%, it could send to our compactor pelletizing machine to make granules directly. We could supply the PP PE film washing line between 300kg/h to 2000kg/h. Although our standard plastic woven bag recycling lines are sufficient for most facilities, to meet your specific needs, custom lines with additional machinery are warmly welcomed.

Application

LDPE agriculture film,LLDPE stretch film,PP woven bag,PP jumbo bag scrap.

LDPE agriculture film

LLDPE wrapping film

PP woven bag

PP jumbo bag

After process

After process

After process

After process

Parameter

Model Power Water  Capacity
RM300 85kw/h 4-6 t/h 300kg/h
RM500 155kw/h 6-8 t/h 500kg/h
RM1000 320kw/h 8-10 t/h 1000kg/h

Cleaning Process

  • * Shredder crusher as a group to cut the big bale or normal film shape.
  • * Unique design new angle of blades in crusher to max capacity.
  • * High speed friction washer and label remover system to separate film and stickers especially for LLDPE packaging film.
  • * Film squeezing machine or centrifuge dryer optionally.
  • * Easy operation with low consumption.
No Equipment name Quantity
1 Belt conveyor 1
2 Wet film crusher 1
3 Double screw conveyor 1
4 Film floating washer 1
5 Screw conveyor 1
6 High speed friction washer 1
7 Screw conveyor 1
8 Squeezing machine 1
9 Storage hopper 1
10 Electric panel 1

Quality Assurance

Final moisture between 3%-5%.

Use world famous brand parts,like Siemens motor,Fuji Inverter,SKF bearing,SUS 304 stainless steel, SKD-11 blades,etc.



Faq

Q

Are you trading company or manufacturer?

A

We are a manufacturer which producing the machines by ourselves.

Q

What’s your guarantee or the warranty of the quality if we buy your machines?

A

Our warranty year is one year. During the period, we provide you spare parts free of charge asap. But the technical guide is forever.

Q

How can I install my machine when it arrives?

A

We will send the instruction manual and videos to you,your workers can install the machine accorded to it. If the situation is ok, we can arrange our engineer to your factory, who will teach your labors how to install machines.

Q

How to maintenance machines in factory?

A

We will provide maintenance instruction, it will mark the oil model and time. And how many times you should check the machines. Any problems about machines, you can ask us anytime.

Q

If our machine is not working suddenly, but we have not spare parts, how to solve?

A

We promise our machine’s quality. Also we will prepare enough spare parts from the beginning for using urgently. Some vulnerable parts(blades), we will suggest you to buy. The last way,we send you spare parts by DHL.

Q

How to maintence recycling machine:

A

We will send you manuals for product maintenance and how to solve common problems. By the way, you can contact with us, we will try our best to teach you by instruction book or video.

Q

Warranty:

A

We provide 12 months’ warranty period usually.In this Period, any machine’s quality problem,we will send spare parts soon by DHL. We will do our best to teach your worker how to change the spare parts by video or instruction.

Q

24hours technical service:

A

We will online 24 hours every day, You can contact with us anytime. Our engineer will send you machine maintenance manuals.

×
