PP Woven Bag Jumbo Big Cement Bag Recycling Washing Line
Retech Machine PP woven bag washing line: mainly used to process PP woven bags, PP jumbo bags and other waste plastic materials. Also supports LDPE agricultural film, LLDPE stretch film and other materials.
At a Glance
Equipment Overview
- Category
- Washing Machine
- Capacity options
- 300kg/h, 500kg/h, 1000kg/h
- Typical application
- LDPE agriculture film,LLDPE stretch film,PP woven bag,PP jumbo bag scrap.
- Output
- Clean flakes or recycled pellets — confirmed per project
Product 01
Overview
Our PP woven bag big bag crushing/washing/squeezing/drying recycling line is mainly designed to deal with waste plastic materials like PP woven bag, PP jumbo big bag, materials of LDPE agriculture film, LLDPE wrapping stretch film also supports. offers pp woven bag recycling solutions that are high output and low energy consumption. As a top manufacturer of plastic recycling manufacturer, Retech Machinery offers PP woven bag recycling machines solutions with high output and low energy consumption.
The whole PP woven bag washing recycling machine process includes shredder, water rinsing, friction washing, drying and washing system, the final flakes humidity will be less than 5%, it could send to our compactor granulating machine to make new granules directly. We could supply PP PE film bag washing line between 300kg/hr to 2000kg/hr. Although our standard plastic woven bag recycling lines are sufficient for most facilities, to meet your specific needs, custom lines with additional machinery are warmly welcomed.
Product 02
Applications & Suitable Materials
LDPE agriculture film,LLDPE stretch film,PP woven bag,PP jumbo bag scrap.
Product 03
Cleaning Process
- * Shredder crusher as a team to cut the big bale or normal film or PP big bag.
- * Unique design new angle of blades in crusher to max crushing capacity.
- * High speed friction washer and label remover system to separate film and stickers especially for LLDPE packaging film.
- * PP PE Film Bag squeezing machine or centrifuge dryer optionally.
- * Easy operation with low consumption of whole PP woven bag washing plant.
| No | Equipment name | Quantity |
|---|---|---|
| 1 | PP Big Bag Shredder | 1 |
| 2 | Wet PP film bag crusher | 1 |
| 3 | High speed friction washer | 1 |
| 4 | PP PE Film floating washer | 1 |
| 5 | Hot floating tank | 1 |
| 6 | PP PE cold washing tank | 1 |
| 7 | Friction washer | 1 |
| 8 | PP Woven Bag Squeezing machine | 1 |
| 9 | Storage hopper | 1 |
| 10 | Electric panel | 1 |
Technical Data
Specifications & Parameters
| Model | Power | Water | Capacity |
|---|---|---|---|
| RM300 | 85kw/h | 4-6 t/h | 300kg/h |
| RM500 | 155kw/h | 6-8 t/h | 500kg/h |
| RM1000 | 320kw/h | 8-10 t/h | 1000kg/h |
Quality
Quality Assurance
Final PP flakes moisture between 3%-5%.
Use world famous brand parts,like Siemens motor,Fuji Inverter,SKF bearing,SUS 304 stainless steel, SKD-11 blades,etc.
Video
Machine Video
Video plays on demand. Source: Retech Machine official channel.
Ready to review your material?
Need a Configuration for PP Woven Bag Jumbo Big Cement Bag Recycling Washing Line?
Send us your material form, contamination level and target capacity. We will come back with a preliminary process route and equipment configuration.
