Post Consumer LDPE Agriculture Film LLDPE Wrap Stretch Film Crushing Washing Squeezing Line
Waste plastic LLDPE stretch film washing line is used to cleaning post consumer packaging films or wrap scrap from warehouses or shopping stores packaging industry.
At a Glance
Equipment Overview
- Category
- Washing Machine
- Capacity options
- 300kg/h, 500kg/h, 1000kg/h
- Typical application
- LLDPE packaging film,LLDPE stretch film,LDPE agriculture film,LLDPE wrapping film.
- Output
- Clean flakes or recycled pellets — confirmed per project
Product 01
Overview
Our LLDPE film washing recycling line is designed to processing waste post consumer LLDPE baled or loose packaging film by complete automatic LDPE LLDPE film recycling system.
Due to the contaminations like glue or paper stickers on surface of LLDPE film,it is hard to get separated by traditional way, RETECH technical team designed a new paper film separation system to get film fully washing and recycling.Equipped with conical film squeezing machine on drying section,we can promise the humidity of final LLDPE film less than 5%. LLDPE film after processing by our film washing line,then it could send to next our RCSJ series LLDPE film pelletizing recycling machine for making granulation.
Product 02
Applications & Suitable Materials
LLDPE packaging film,LLDPE stretch film,LDPE agriculture film,LLDPE wrapping film.
Product 03
Cleaning Process
- * Metal detector and crusher as a group to cut the film into small and avoid harm to knife in crusher.
- * Floating wash tank for pre-wash LLDPE film.
- * Label remover system to separate film and stickers especially for LLDPE packaging film.
- * Film squeezing machine efficiency.
- * Easy operation with low power consumption.
| No | Equipment name | Quantity |
|---|---|---|
| 1 | Belt conveyor | 1 |
| 2 | Wet film crusher | 1 |
| 3 | Double screw conveyor | 1 |
| 4 | Film floating washer | 1 |
| 5 | Screw conveyor | 1 |
| 6 | Film Label Separation System | 1 |
| 7 | Screw conveyor | 1 |
| 8 | Squeezing machine | 1 |
| 9 | Storage hopper | 1 |
| 10 | Electric panel | 1 |
Technical Data
Specifications & Parameters
| Model | Power | Water | Capacity |
|---|---|---|---|
| RM300 | 85kw/h | 4-6 t/h | 300kg/h |
| RM500 | 155kw/h | 6-8 t/h | 500kg/h |
| RM1000 | 320kw/h | 8-10 t/h | 1000kg/h |
Quality
Quality Assurance
Final moisture between 3%-5%. Dry and clean.
Use world famous brand parts,like Siemens motor,Fuji Inverter,SKF bearing,SUS 304 stainless steel, SKD-11 blades,etc.
FAQ
Post Consumer LDPE Agriculture Film LLDPE Wrap Stretch Film Crushing Washing Squeezing Line — Questions
Are you trading company or manufacturer?
We are a manufacturer which producing the machines by ourselves.
What’s your guarantee or the warranty of the quality if we buy your machines?
Our warranty year is one year. During the period, we provide you spare parts free of charge asap. But the technical guide is forever.
How can I install my machine when it arrives?
We will send the instruction manual and videos to you,your workers can install the machine accorded to it. If the situation is ok, we can arrange our engineer to your factory, who will teach your labors how to install machines.
How to maintenance machines in factory?
We will provide maintenance instruction, it will mark the oil model and time. And how many times you should check the machines. Any problems about machines, you can ask us anytime.
If our machine is not working suddenly, but we have not spare parts, how to solve?
We promise our machine’s quality. Also we will prepare enough spare parts from the beginning for using urgently. Some vulnerable parts(blades), we will suggest you to buy. The last way,we send you spare parts by DHL.
How to maintence recycling machine:
We will send you manuals for product maintenance and how to solve common problems. By the way, you can contact with us, we will try our best to teach you by instruction book or video.
Warranty:
We provide 12 months’ warranty period usually.In this Period, any machine’s quality problem,we will send spare parts soon by DHL. We will do our best to teach your worker how to change the spare parts by video or instruction.
24hours technical service:
We will online 24 hours every day, You can contact with us anytime. Our engineer will send you machine maintenance manuals.
