High-Efficiency Food Grade PET Bottle Recycling Washing Machine Plant
Trust Retech Machine's PET bottle recycling and washing line, designed specifically for the reprocessing of used PET bottles (such as mineral water bottles, cola bottles, Pepsi bottles, etc.).
At a Glance
Equipment Overview
- Category
- Washing Machine
- Models
- RM-1000, RM-3000, RM-5000
- Capacity options
- 1000kg/h, 3000kg/h, 5000kg/h
- Typical application
- PET Bottle,PET Baled Brick,Waste PET rPET Cola Bottle,Other Mineral Water Bottles.
- Output
- Clean flakes or recycled pellets — confirmed per project
Product 01
Overview
Our high efficiency automatic PET bottle recycling washing line plant is used to recycle and reprocessing waste plastic PET bottle,Cola bottle,Pesi cola bottle,Mineral water bottle,etc.
PET flakes after processing by our PET bottle recycling machine will be in low humidity which is less than 1%. Dry and clean flakes could send to our PET pelletizing machine to make granules directly.We could supply the PET bottle plastic washing line between 500kg/h to 3000kg/h.
Product 02
Applications & Suitable Materials
PET Bottle,PET Baled Brick,Waste PET rPET Cola Bottle,Other Mineral Water Bottles.
Product 03
Cleaning Process
- * Strong baler to open baled PET bottle brick from tight to loosen.
- * Moving trommel screen to separate small stone,metals firstly.
- * High speed friction washer and hot washing tank system to wash the dirt in high efficiency.
- * High centrifugal force dehydrator dryer in moving speed 2000 RPM .
- * Easy operation PET recycling line with low impurities below 150 PPM.
| No | Equipment name | Quantity |
|---|---|---|
| 1 | Bale Opener | 1 |
| 2 | Trommel Screen Separator | 1 |
| 3 | Manual Sorting Table | 1 |
| 4 | PET Label Remover | 1 |
| 5 | PET Bottle Grinder | 1 |
| 6 | High Speed Friction Washer | 1 |
| 7 | Hot Washing Tank | 1 |
| 8 | Dewatering Machine | 1 |
| 9 | Zigzag Label Remover | 1 |
| 10 | Packaging System | 1 |
Technical Data
Specifications & Parameters
| Model | Power | Water | Capacity |
|---|---|---|---|
| RM-1000 | 230kw/h | 4-5 t/h | 1000kg/h |
| RM-3000 | 420kw/h | 6-8 t/h | 3000kg/h |
| RM-5000 | 580kw/h | 8-10 t/h | 5000kg/h |
Quality
Quality Assurance
Final moisture below 1%. Dry and clean PET flakes.
Use world famous brand parts,like Siemens motor,Fuji Inverter,SKF bearing,SUS 304 stainless steel, SKD-11 blades,etc.
